1.The Shaft is made of seamless pipe and solid shaft(aisi4140)
2.Cage adopts Flat noddles type use round bar
3. Hammer Material is wear-resistant (NM400) and multiple uses
4. The sterilized palm fruit is separated, and the fruit pulp is directly entered into the pressing machine. After the core is polished, the surface fiber is removed, and there is no need to separate the fiber, and it can directly enter the nuclear crushing section! Reduced process and oil loss!
Item | Model | ||
YHNS-3 | YHNS-5 | ||
Capacity FFB ton/hr | 3 | 5 | |
Power kw 380V/3P/50Hz | 5.5 | 7.5 | |
Shaft Speed rpm/min | 280-300 | 280-300 | |
Cage Diameter mm: | 450 | 600 | |
After process Broken rate % | 99.5% | 99.5% | |
Driver connect Model | Pulley+V-belt | Pulley+V-belt | |
Dimension | L（mm） | 1400 | 1700 |
W（mm） | 820 | 1000 | |
H（mm） | 910 | 1110 | |
Weight | kg | 263 | 380 |
